REALIZATION

InTouch to siemens WinCC SCADA Migration.

Challenge :Upgrade an outdated Intouch SCADA System to siemens WinCC without disrupting production.

Our solution:

Data collection
Program conversion & optimization
Station-by-station simulation
On-site testing & commissioning
Final acceptance & validation

Results:

Maintained 100% data integrity
Zero unplanned downtime during cut-over
Enhanced monitoring accuracy
Delivered a robust ,scalable siemens WinCC SCADA platform

AUTOMATED WOOD NAILING MACHINE

1-machine study & component selection

analyze existing wood-nailing Machin's mechanics ,and control architecture .
set performance targets (nailing speed ,accuracy cycle time).
specify appropriate nail feeder magazines & actuators for chosen wood types .
select sensors to ensure precise positioning .

2-PLC programming & Electrical cabinet.

choose siemens S7-1200 PLC for I/O capacity and networking .
design touchscreen HMI for recipe management ,monitoring & alarms .
Develop program mixed with Ladder logic & SCL .
lay out power distribution ,control relays, terminal blocks and Profinet switches .

3- Factory acceptance testing(SAT)

Conduct dry-run tests to validate logic ,timing and safety circuits without wood .
verify emergency stop , light curtains and interlock functionality .
deliver full documentation ,PLC code , electrical schematics ,user manuals.
